Keystone KTLD-2LT8-UV-PS15C-BL-VDIM 2-Lamp Selectable Dimming Driver External LED Tubes
- Buy 12 for $20.50 each and save 7%
- Keystone KTLD-2LT8-UV-PS15C-BL-VDIM
Keystone KTLD-2LT8-UV-PS15C-BL-VDIM 2-Lamp Power-Selectable Driver External LED Tubes
Designed for use with Keystone's Type C External Driver LED T8 tubes. Can operate all sizes of Keystone's Type C LED tubes, including 2', 3', 4' and ubends. This driver operates 1-2 of these lamps and allows for crisp 0-10V dimming (dimmer not included). Select the light level on the driver itself with 100%, 7o% or 50% output.
| Manufacturer | Keystone |
|---|---|
| Shipping Speed | Usually ships in 1-2 business days |
| Volts | 120-277V |
| Input Current Max | 0.31 |
| Input Power Max | 37w |
| Input Frequency | 50/60Hz |
| Max. Current | 300 mA |
| Power Factor | >0.9 |
| THD Max | N/A |
| Output Current | 300 mA |
| Output Voltage | 25-48Vdc |
| Output Power | 30W |
| Efficiency | 86% |
| Case Style | N/A |
| Dimmable | 0-10V |
| Length (M.O.L.) Inches | 11.02 |
| Width (Inches) | 1.18 |
| Height (Inches) | 0.87 |
| Maximum Temp | 113°F |
| Minimum Starting Temp | -4°F |
| Wet/Damp Rated | Damp Rated |
| Certifications | UL |
| Warranty | 10 Year |
| Manufacturer Part # | KTLD-2LT8-UV-PS15C-BL-VDIM |
| Manufacturer Order # | N/A |
| Premier Part # | KTLD-2LT8-UV-PS15C-BL-VDIM |
