Keystone KTLD-4LT5HO-UV-12C-VDIM 4-Lamp Dimming Driver External LED T5
- Buy 25 for $46.95 each and save 11%
- Keystone KTLD-4LT5HO-UV-12C-VDIM
Keystone KTLD-4LT5HO-UV-12C-VDIM 4-Lamp Dimming Driver External LED T5. Constant Current LED Driver for Type C LED T5HO. Designed for specific use with Keystone's Type C External Drive LED T5 tubes. This driver operates 3-4 of these 2' F24T5/HO replacement lamps and allows for crisp 0-10V dimming (dimmer not included).
Brochures & Cut Sheets
Manufacturer | Keystone |
---|---|
Volts | 120-277V |
Input Current Max | 52W |
Input Power Max | 52W |
Input Frequency | 50/60Hz |
Max. Current | 0.49A@120V |
Power Factor | >0.9 |
THD Max | <20% |
Output Current | 270 mA x 4 Channels |
Output Voltage | 36-45Vdc |
Output Power | 46W |
Efficiency | 88% |
Case Style | N/A |
Dimmable | 0-10V |
Length (M.O.L.) Inches | 9.69 |
Width (Inches) | 1.61 |
Height (Inches) | 1.24 |
Maximum Temp | 113°F |
Minimum Starting Temp | -4°F |
Wet/Damp Rated | Damp Rated |
Certifications | UL |
Warranty | 5 Year |
Manufacturer Part # | KTLD-4LT5HO-UV-12C-VDIM |
Premier Part # | KTLD-4LT5HO-UV-12C-VDIM |
