Keystone KTLD-4LT5HE-UV-8C-VDIM 4-Lamp Dimming Driver External LED T5
Constant Current LED Driver for Type C LED T5HE. Designed for specific use with Keystone's Type C External Drive LED T5 tubes. This driver operates 3-4 of these 2' LED T5HE lamps and allows for crisp 0-10V dimming (dimmer not included).
Brochures & Cut Sheets
| Manufacturer | Keystone |
|---|---|
| Volts | 120-277V |
| Input Current Max | 36W |
| Input Power Max | 36W |
| Input Frequency | 50/60Hz |
| Max. Current | 0.34A@120V |
| Power Factor | >0.9 |
| THD Max | <20% |
| Output Current | 185 mA x 4 Channels |
| Output Voltage | 36-45Vdc |
| Output Power | 32W |
| Efficiency | 89% |
| Case Style | N/A |
| Dimmable | 0-10V |
| Length (M.O.L.) Inches | 9.69 |
| Width (Inches) | 1.61 |
| Height (Inches) | 1.24 |
| Maximum Temp | 113°F |
| Minimum Starting Temp | -4°F |
| Wet/Damp Rated | Damp Rated |
| Certifications | UL |
| Warranty | 5 Year |
| Manufacturer Part # | KTLD-4LT5HE-UV-8C-VDIM |
| Premier Part # | KTLD-4LT5HE-UV-8C-VDIM |
