TCP L17PLVD5050K Vertical LED PL BR30 Dimmable 17W 5000K Uses Ballast

TCP L17PLVD5050K Vertical LED PL BR30 Dimmable 17W 5000K Uses Ballast

Be the first to review this product

$17.95
OR

Quick Overview


  • Premier# LPL50K17WG24VERT/B-T

  • TCP L17PLVD5050K Vertical LED PL Reflector 17W 5000K

Details

TCP L17PLVD5050K Vertical LED PL BR30 Dimmable 17W 5000K Uses Ballast

TCP has put a new twist on CFL plug-in replacement lamps with their vertical LED PL lamps in a reflector style. Perfect for commercial downlight applications in retail, office or hospitality. Replaces 4-pin CFL PL fluorescent lamps with G24 base type. Available as LED BR30 sizes in 9W and 17W as well as LED BR40's in 19W. Color temp options include 2700K, 3000K, 4100K and 5000K. These are Type A LED PL lamps that utilize existing CFL ballasts to operate. Check cut sheet below for ballast compatibility guide. Dimmable with a working dimmable CFL PL ballast - 0-10V dimming recommended.


Brochures & Cut Sheets

TCP LED PL Spec Sheet TCP LED PL Spec Sheet

Additional Information

Watts 17W
CFL Equivalent 26W
Lamp Type 4-Pin PL
Lumens 1950
Lumens Per Watt 114.71
Volts 120-277V, 347V (ballast dependent)
CRI 80
Color Temperature 5000K
Dimmable With Compatible Dimmable Ballast
Base Type G24q/GX24q
Beam Angle 110°
Orientation Vertical
Clear/Frosted Lens Frosted
Length (M.O.L.) Inches 5.1
Width (Inches) 3.7
Height (Inches) N/A
Rated Hours 50,000
DLC Listed No
Wet/Damp Rated Damp Rated
Maximum Temp 40°C
Minimum Starting Temp -30°C
Certifications UL
Case Quantity 12
Warranty 5 Year
Manufacturer TCP
Manufacturer Part # L17PLVD5050K
Manufacturer Order # L17PLVD5050K
Premier Part # LPL50K17WG24VERT/B-T
