TCP L17PLVD5030K Vertical LED PL BR30 Dimmable 17W 3000K Uses Ballast

  • Buy 12 for $15.47 each and save 11%
  • Buy 96 for $13.73 each and save 21%
  • Premier# LPL30K17WG24VERT/B-T
  • TCP L17PLVD5030K Vertical LED PL Reflector 17W 3000K

TCP L17PLVD5030K Vertical LED PL BR30 Dimmable 17W 3000K Uses Ballast

TCP has put a new twist on CFL plug-in replacement lamps with their vertical LED PL lamps in a reflector style. Perfect for commercial downlight applications in retail, office or hospitality. Replaces 4-pin CFL PL fluorescent lamps with G24 base type. Available as LED BR30 sizes in 9W and 17W as well as LED BR40's in 19W. Color temp options include 2700K, 3000K, 4100K and 5000K. These are Type A LED PL lamps that utilize existing CFL ballasts to operate. Check cut sheet below for ballast compatibility guide. Dimmable with a working dimmable CFL PL ballast - 0-10V dimming recommended.


Brochures & Cut Sheets

TCP LED PL Spec Sheet TCP LED PL Spec Sheet

More Information
Manufacturer TCP
Watts 17W
CFL Equivalent 26W
Lamp Type 4-Pin PL
Lumens 1800
Lumens Per Watt 105.89
Volts 120-277V, 347V (ballast dependent)
CRI 80
Color Temperature 3000K
Kelvin 3000K
Dimmable With Compatible Dimmable Ballast
Base Type G24q/GX24q
Bulb Shape PL
Beam Angle 110°
Orientation Vertical
Lens Type Frosted
Length (M.O.L.) Inches 5.1
Width (Inches) 3.7
Height (Inches) N/A
Rated Hours 50,000
DLC Listed No
Wet/Damp Rated Damp Rated
Maximum Temp 40°C
Minimum Starting Temp -30°C
Certifications UL
Case Quantity 12
Warranty 5 Year
Manufacturer Part # L17PLVD5030K
Manufacturer Order # L17PLVD5030K
Premier Part # LPL30K17WG24VERT/B-T
