Green Creative 97747 17PLL/840/DIR 17W LED PLL 4000K Replaces 40W CFL
- Premier# LPLL40K17W2G11/B-GC
- Green Creative 17PLL/840/DIR 97748
- 17W LED PLL - Uses Ballast - 4000K - 2100 Lumens - 2G11 Base
Green Creative 17PLL/840/DIR 97747 LED PLL 17W 4000K (Uses Existing Ballast)
Replace your 40W CFL PLL lamps with Green Creative's 17W LED PLL. From Green Creative's PL Edge Series that includes a the 14.5W LED PLL. Green Creative's 17W LED PLL is compatible with 40W electronic instant start or program start ballasts. Simply install the bulb; no rewiring needed! Suitable for use in totally enclosed fixtures. Wide beam design with a 280° light emitting area. 0-10V dimming depending on the ballast. 17W LED PLL from Green Creative available in 3000K, 3500K and 4000K
Brochures & Cut Sheets
| Watts | 17W |
|---|---|
| Fluorescent Equivalent | 40W |
| Old LED Version | N/A |
| Lumens | 2100 |
| Lumens Per Watt | 124 |
| Volts | 120-277V |
| CRI | 80 |
| Color Temperature | 4000K |
| Dimmable | 0-10V |
| Base Type | 2G11 |
| Wiring | N/A |
| Lens Type | Frosted |
| Construction | N/A |
| Length (M.O.L.) Inches | 22.48 |
| Width (Inches) | 1.71 |
| Height (Inches) | N/A |
| Beam Angle | 120° |
| Light Emitting Area | 280° |
| Rated Hours | 50,000 |
| DLC Listed | No |
| Wet/Damp Rated | Damp Rated |
| Maximum Temp | N/A |
| Minimum Starting Temp | N/A |
| Certifications | UL Listed |
| Case Quantity | 6 |
| Warranty | 5 Year |
| Manufacturer Part # | 17PLL/840/DIR |
| Manufacturer Order # | 97747 |
| Premier Part # | LPLL40K17W2G11/B-GC |
